Cement Mill

Cement Mill are important cement making machine mainly used to make deep crushing of the crushed materials. The cement mills made by Lanyu have been widely applied to grind wet or dry materials in the industries of producing cement, silicate products, and new type of construction materials, refractory matter, chemical fertilizer, ferrous and non-ferrous metal and glass ceramics.

The Inner Structure of Cement Mill

Cement mill is made of a horizontal cylinder, a feeding and discharging hollow shaft, grinding head and other parts. The cylinder is a cylindrical tube. There is a grinding body in the tube. The cylinder is made of steel and fixed by a steel liner and cylinder. Grinding body is generally steel balls. These steel balls are installed in the tube according to different diameters and a certain proportion. The grinding body can also be steel sections.

Features of Cement Mill

1. Strong adaptability to raw materials.

2. Continuous production, large crushing ratio.

3. Easy adjustment of grinding fineness.

4. It can not only be used for dry production and wet production, but also can conduct simultaneous grinding and drying operations.

Working Principle of Cement Mill

This machine is a horizontal cylinder rotating device, with the outer gear transmission, two warehouses and grid type China cement mill. The materials get into the first warehouse through the feeding device evenly, with the steps lining board or corrugated lining board and different sizes of steel balls in the warehouse. The centrifugal force produced by the cylinder puts the steel balls to a certain height and then makes them fall down, which has a strong impact and grinding effect on the materials.

After the coarse crushing process in the first warehouse, the materials get into the second warehouse, with the scale board embedded and steel balls in the warehouse. The materials will be further crushed in this warehouse. The powder will be discharged by the uploading plank. Then, the grinding work will be finished.

Technical Parameters of Cement Mill
